9907-167 单抽/进蒸汽轮机

概述

基本细节:9907-167 505E数字州长伍德沃德

505E控制器设计用于操作各种尺寸和应用的单抽/进蒸汽轮机。该汽轮机控制器包括专门设计的算法和逻辑，以启动，停止，控制和保护单一提取和或进入汽轮机或涡轮膨胀器。驱动发电机、压缩机、泵或工业风扇。505E控制器独特的PlD结构使其非常适合需要控制蒸汽装置参数的应用，如涡轮种子。tudine旁边。涡轮压力。该控制的特殊PID-o-P1D逻辑允许在正常涡轮运行期间稳定控制和在工厂扰动期间无颠簸控制模式转移，最大限度地减少过程过冲或欠冲条件。505E控制器通过被动或主动速度探头感知汽轮机种子，并通过连接到汽轮机蒸汽阀的HP和lp执行器控制汽轮机

505E控制器通过4-2 mA传感器感知提取和进入压力，并通过比率计功能使用piD来精确控制提取和/或进入头部压力，同时保护涡轮机在其设计的操作范围之外运行。控制器使用特定涡轮机的OEM蒸汽图来计算其阀对阀解耦算法以及涡轮机运行和保护限制。

Woodward 9907-167 505E数字总督是精心设计的操作不同尺寸和应用的单提取和/或入场汽轮机。它结合了专门的算法和逻辑定制的完全控制和保护这些涡轮机，无论是驱动发电机，压缩机，泵，或工业风扇，505E控制配备管理其操作的各个方面。

汽轮机运行的先进控制算法

505E控制器的突出特点之一是其独特的PID结构，使其高度适应需要精确控制蒸汽厂参数的应用。从涡轮速度和负载到入口和排气压力，提取入口集压头压力和线路功率，505E控制在保持最佳运行方面表现出色。

平稳和稳定的控制过渡505E控制器的专用pid到pid逻辑确保在常规涡轮机运行期间的稳定性，并在意外的工厂中断期间无缝过渡控制模式。这种能力最大限度地减少了过程偏差，有助于更平稳、更高效的整体操作。

summarize

Basic details :9907-167 505E figures Governor Woodward

The 505E controller is designed to operate single pump/feed steam turbines of various sizes and applications. The turbine controller includes specially designed algorithms and logic to start, stop, control and protect a single extraction and or entry into the turbine or turbine expander. Drive generators, compressors, pumps or industrial fans. The 505E controller's unique PlD structure makes it ideal for applications where steam plant parameters need to be controlled, such as turbine seeds. Next to tudine. Turbine pressure. The control's special PID-o-P1D logic allows for stable control during normal turbine operation and no bump-control mode transfer during plant disturbances, minimizing process overshoot or undershoot conditions. The 505E controller senses the turbine seed through passive or active speed probes and controls the turbine through HP and lp actuators connected to the turbine steam valve

The 505E controller senses the extraction and entry pressure via a 4-2 mA sensor and uses piD via the ratio meter function to precisely control the extraction and/or entry head pressure while protecting the turbine from operating outside its designed operating range. The controller uses the OEM steam diagram for a specific turbine to calculate its valve-to-valve decoupling algorithm and turbine operation and protection limits.

Woodward 9907-167 505E Digital Governor is carefully designed to operate single extraction and/or entry steam turbines of different sizes and applications. It combines specialized algorithms and logic customized to fully control and protect these turbines, whether driving generators, compressors, pumps, or industrial fans, and the 505E control is equipped to manage every aspect of their operation.

Advanced control algorithm of steam turbine operation

One of the outstanding features of the 505E controller is its unique PID construction, which makes it highly suitable for applications requiring precise control of steam plant parameters. From turbine speed and load to inlet and exhaust pressure, extracting inlet head pressure and line power, the 505E control excels at maintaining optimal operation.

Smooth and stable control transitions The 505E controller's dedicated PID-to-PID logic ensures stability during conventional turbine operation and seamless transition of control modes during unexpected plant outages. This capability minimizes process deviations and contributes to a smoother and more efficient overall operation.
