DS2001TXDG1ABA 数据传送模块 具备数据传输功能

DS2001TXDG1ABA 用作DC2000驱动器的接口 DS2001TXDG1ABA
这通用电气DC电源和外表委员会DS2001TXDG1ABA用作DC2000驱动器的接口。因为每个保险丝都有一个LED指示灯，可以指示与其相关的保险丝何时熔断，因此电路板的故障扫除和可用性得到了改善。您有必要完成以下步骤才干查看主板并查看指示灯LED是否亮起。
DS2001TXDG1ABA板被标记为动态制动缓冲中板，是通用电气制造的 MarkV系列的一部分。IXTD 板所需的操作经过衔接的电源!接口板(MCP)的电路提供。当衔接 MCP 和 IXTD 板时，它们经过四针衔接器衔接。安装电路板时，它将安装在外部，而且尺寸有必要满意动态制动 IGBTQ 最坏情况下的开关需求。缓冲板的意图是用于约束IGBT 上的电压瞬变以及驱动器的一切已知操作条件。
DS2001TXDG1ABA板的另一个功能是调理 IGBT 栅极驱动器只板的输出，使其可以匹配 AT 结构驱动器的电气特性。AT 结构驱动器有可变和稳定扭矩使用。可变转矩使用的驱动器额定输出电流为500ARMS

DS2001TXDG1ABA Used as the interface for the DC2000 driver DS2001TXDG1ABA

This GE DC power supply and exterior Council DS2001TXDG1ABA is used as an interface for the DC2000 driver. Because each fuse has an LED indicator that indicates when the fuse associated with it has blown, fault cleaning and usability of the board is improved. It is necessary to complete the following steps to view the motherboard and see if the indicator LED is on.

The DS2001TXDG1ABA board is labeled as a dynamic brake buffer medium board and is part of the MarkV series manufactured by General Electric. IXTD board required to operate through connected power supply! Interface board (MCP) circuit is provided. When connecting the MCP and IXTD boards, they are connected via a four-pin adapter. When the circuit board is installed, it will be mounted externally, and the size is necessary to satisfy the switching requirements of dynamic braking IGBTQ in the worst case. The buffer board is intended to constrain the voltage transients on the IGBT and all known operating conditions of the driver.

Another function of the DS2001TXDG1ABA board is to condition the output of the IGBT gate driver only board so that it can match the electrical characteristics of the AT structure driver. AT structure drivers are available with variable and stable torques. The rated output current of the driver for variable torque is 500ARMS
