VMIVME 2540-300 智能计数器/控制器

VMIVME-2540-30024-Channel智能计数器/控制器
ICC反电路由六个可编程体系时序控制器(STCS)组成。每个STC为ICC供应四个高速计数器/波形合成接口，为VMIVME-2540供应24通道数字丈量和控制。STC计数器能够独自装备，也能够最多装备4个，以完成各种丈量和控制功用。
VMIVME 2540-300  是 VMIC/GE Fanuc 板卡的特定模块之一，具有作为智能计数器控制器运转的功用。该设备能够核算多达 4个千兆事情。它装备了一系列 24 个离散输出通道，这些通道能够通过各种板载跳线模块选项进行编程。这些跳线能够在很宽的极点电压电平下作业。
24 个输出通道旨在供应 12 位分辨率。它们能够在 +/- 10 V 的速率下供应和吸收高达 10 毫安的电流。
为了使用VMIVME 2540-300  进行离线测试，模拟输入规划为与外部电路断开联接。
VMIVME 2540-300  模块规划有 VMEbus 从站接口，能够供应 4、8、16 或 24 通道的数字信号丈量和信号生成功用。这些或许的丈量和信号输出功用由一系列集成体系时序控制器以及一系列相关的接口逻辑应用。

VMIVME-2540-30024-Channel Intelligent counter/controller

The ICC inverse circuit is composed of six programmable system timing controllers (STCS). Each STC supplies four high-speed counter/waveform synthesis interfaces for the ICC and 24 channels of digital measurement and control for the VMIVME-2540. STC counters can be equipped alone or up to four to perform a variety of measurement and control functions.

The VMIVME 2540-300 is one of the specific modules of the VMIC/GE Fanuc board, which functions as an intelligent counter controller. The device is capable of accounting for up to 4 gigabits of events. It is equipped with a series of 24 discrete output channels that can be programmed with various onboard jumper module options. These jumpers can operate at a wide range of pole voltage levels.

24 output channels are designed to provide 12-bit resolution. They are capable of supplying and absorbing up to 10 milliamps of current at rates of +/ -10 V.

For off-line testing with the VMIVME 2540-300, the analog input is planned to be disconnected from the external circuit.

The VMIVME 2540-300 module is planned with a VMEbus slave interface and is capable of providing digital signal measurement and signal generation functions in 4, 8, 16 or 24 channels. These possible measurement and signal output functions are applied by a series of integrated architecture timing controllers and a series of associated interface logic applications.
