IC693MDL646是90-30系列可编程逻辑控制器（PLC）平台的一个组件模块，该平台最初由GE Fanuc制造，现由艾默生自动化制造。该模块设计用于接受24 VDC输入信号，并支持正负逻辑接线配置。它有一组16个输入通道，并配有一个公共电源输入端子。
该模块的输入电压范围为0-30 VDC，标称值为24 VDC，额定电压下的输入电流为7 mA。此外，它还具有特定的开态和关闭状态电压，以及相应的开态和关断状态电流。功耗方面，它有一个特定的功耗值，这取决于操作条件和供电电压。
IC693MDL646模块配有20个连接端子，这些端子由摆动门覆盖，摆动门还提供接线插件，作为如何与设备和电源建立连接的参考。该模块还有一个颜色代码，表明它是一个低压模块，并安装了单个通道状态LED和模块正常LED。
IC693MDL646模块旨在适应各种二进制或开/关现场设备，如按钮设备、开关、接近开关和辅助触点。在工业自动化和控制系统中，它扮演着关键角色，确保信号从传感器和其他输入设备准确地传输到PLC，从而实现精确的控制和监测。
The IC693MDL646 is a component module of the 90-30 series Programmable Logic Controller (PLC) platform, originally manufactured by GE Fanuc and now manufactured by Emerson Automation. The module is designed to accept 24 VDC input signals and supports positive and negative logic wiring configurations. It has a set of 16 input channels and is equipped with a common power input terminal.
The module has an input voltage range of 0-30 VDC, a nominal value of 24 VDC, and an input current of 7 mA at rated voltage. In addition, it has specific on-state and off-state voltages, and corresponding on-state and off-state currents. In terms of power consumption, it has a specific power consumption value, which depends on the operating conditions and supply voltage.
The IC693MDL646 module is equipped with 20 connection terminals, which are covered by swinging doors, which also provide wiring plug-in as a reference for how to connect to the device and power supply. The module also has a color code indicating that it is a low-voltage module and has a single channel status LED and a module normal LED installed.
The IC693MDL646 module is designed to accommodate a variety of binary or on/off field devices such as push button devices, switches, proximity switches and auxiliary contacts. In industrial automation and control systems, it plays a key role in ensuring that signals are accurately transmitted from sensors and other input devices to the PLC, enabling precise control and monitoring.
