CM10 涂层测厚仪

CM10 涂层测厚仪

磁感应原理：用于测量钢、铁等铁磁金属基体上的非磁性涂镀层的厚度，如油漆层、防腐涂层等。

涡流原理：CM10 用于测量铜、铝、不锈钢等非铁磁性基体上的所有非导电层的厚度。

分辨率与误差：低限分辨力通常在0.1um至10um之间。

误差会根据校准方式（一点或两点校准）有所不同，通常在±(2%H+2)um至±((1～3)%H+10)um之间。

显示与统计功能：大多数型号配备高对比度段码液晶屏（LED背光）。

提供测量次数、最大值、最小值、平均值、标准偏差等统计功能。

校准与工作条件：支持一点、两点校准方式。

工作温度通常在-10℃～+50℃，特殊要求下可达-20℃。

电源与电池：CM10  多数型号使用两节1.5V AA电池。

当电池电量不足时，会有低电压提示。

尺寸与重量：CM10  尺寸大致为149mm×73mm×32mm (H×W×D)。

重量（含电池）通常为200g。

应用领域：CM10  适用于电子业、发电厂、石油化工、航空、建筑等领域，例如磁性金属表面喷漆、汽车表面喷漆等。

CM10 coating thickness gauge

Magnetic induction principle: Used to measure the thickness of non-magnetic coating on steel, iron and other ferromagnetic metal substrates, such as paint layer, anti-corrosion coating, etc.

Eddy current principle: CM10 is used to measure the thickness of all non-conductive layers on non-ferromagnetic substrates such as copper, aluminum and stainless steel.

Resolution and error: The low limit resolution is usually between 0.1um and 10um.

The error will vary depending on the calibration method (one or two point calibration), usually between ±(2%H+2)um and ±((1 to 3)%H+10)um.

Display and statistics: Most models feature a high contrast segment code LCD screen (LED backlight).

Provides statistical functions such as the number of measurements, maximum value, minimum value, average value, and standard deviation.

Calibration and working conditions: Support one point, two point calibration mode.

The operating temperature is usually -10℃ ~ +50℃, and can reach -20℃ under special requirements.

Power and Battery: Most models of the CM10 use two 1.5V AA batteries.

When the battery is low, there is a low voltage warning.

Size and weight: The CM10 is roughly 149mm×73mm×32mm (H×W×D).

The weight (including battery) is usually 200g.

Application: CM10 is suitable for electronics, power plants, petrochemical, aviation, construction and other fields, such as magnetic metal surface painting, automotive surface painting, etc.
