IC693APU302是一款**智能运动配合2轴定位模块(APM)**,属于90-30系列。
该模块是一个完全可编程的模块,由2轴运动控制功能组成,允许在一个集成系统中解决复杂的PLC逻辑功能。它能够控制两个轴或两个伺服电机,以实现运动和位置的同时控制。此外,它可以在标准模式和从动模式下运行。在标准模式下,该模块运行并将控制与PLC存储器中的用户逻辑集成在一起,以实现高性能控制。在从动模式下,该模块为主应用和从应用提供高性能电子传动装置。
IC693APU302该模块的前面板通过特定数量的针脚D壳连接器安装了运动轴端口和高密度端口,以适应伺服连接。此外,它支持使用定制或预组装的电缆进行连接,这些电缆包括不同长度和配置的选项。
该模块还具备一些重要的特性,如独立控制稳定性、自动数据传输设施、最大化的驱动能力和改进的系统性能。它还可以计算和增强位置误差测量,以保持跟踪精度,并用于执行精确控制伺服系统所需的复杂计算。
在配置和编程方面,IC693APU302可以使用VersaPro软件或逻辑开发人员PLC软件进行。关于负载要求,它在+800伏直流电压下的电流为5毫安。
IC693APU302 is the best intelligent motion matching 2-axis positioning module (APM)**, belonging to the 90-30 series.
The module is a fully programmable module consisting of 2-axis motion control functions, allowing complex PLC logic functions to be solved in an integrated system. It is capable of controlling two axes or two servo motors to achieve simultaneous control of motion and position. In addition, it can run in both standard mode and slave mode. In standard mode, the module runs and integrates the control with the user logic in the PLC memory for high performance control. In driven mode, the module provides high performance electronic drives for both master and slave applications.
IC693APU302 The front panel of the module is fitted with motion shaft ports and high-density ports through a specific number of pin D-shell connectors to accommodate servo connections. In addition, it supports connections using custom or pre-assembled cables that include options for different lengths and configurations.
The module also has important features such as independent control stability, automatic data transfer facilities, maximum drive capacity and improved system performance. It can also calculate and enhance position error measurements to maintain tracking accuracy and is used to perform complex calculations needed to precisely control servo systems.
In terms of configuration and programming, the IC693APU302 can be carried out using VersaPro software or Logic Developer PLC software. Regarding the load requirements, it has a current of 5 MA at +800 volts DC.
