H929049B0500  压力传感器      H929049B0500  压力传感器

H929049B0500：信号流线是在一个FBD程序中的信号流的图形表示。信号流线显示变量与功能块之间或不同功能块之间的连接。信号范围指定输入信号或输出信号的值范围。通常的信号范围是0 10V，0 20mA和4 20mA。

FOXBORO   H929049B0500  压力传感器

产品参数

• 型号：H929049B0500
• 测量范围：0-1000Kpa
• 精度：±0.25%
• 输出信号：4-20mA
• 介质温度：-20℃ ~ 105℃
• 存储温度：-40℃ ~ 120℃
• 供电电源：DC 12-36V

产品规格

• 应力传感器：扩散硅压阻式传感器
• 防护等级：IP67
• 材质：316不锈钢
• 连接方式：M20*1.5法兰连接

应用领域

该产品广泛应用于液位、压力、流量等工业自动化领域。

产品使用说明

• 安装前请确认产品型号、测量范围、精度等参数符合使用要求。
• 安装时，请务必按照产品连接方式接线，并注意防护等级。
• 使用中请注意介质温度，避免超出产品测量范围。
• 产品保养时，请勿使用酸碱等腐蚀性清洁剂。

该产品使用扩散硅压阻式传感器，具有精度高、响应速度快、稳定性好等特点。产品采用4-20mA输出信号，能够方便地与各种工业控制系统集成。

H929049B0500: The signal flow line is a graphical representation of the signal flow in an FBD program. Signal streamlines show connections between variables and functional blocks or between different functional blocks. Signal range Specifies the range of values for the input or output signal. The usual signal ranges are 0 10V, 0 20mA and 4 20mA.

FOXBORO H929049B0500 pressure sensor

Product parameter

Model: H929049B0500

Measuring range: 0-1000Kpa

Accuracy: ±0.25%

Output signal: 4-20mA

Medium temperature: -20℃ ~ 105℃

Storage temperature: -40℃ ~ 120℃

Power supply: DC 12-36V

Product specification

Stress sensor: diffused silicon piezoresistive sensor

Protection level: IP67

Material: 316 stainless steel

Connection mode: M20*1.5 flange connection

Application field

The product is widely used in the field of industrial automation such as liquid level, pressure and flow.

Product instructions

Before installation, ensure that the product model, measurement range, and accuracy meet the requirements.

During installation, be sure to connect cables according to the product connection method and pay attention to the protection level.

Please pay attention to the medium temperature during use to avoid exceeding the product measurement range.

Do not use corrosive cleaning agents such as acid and alkali during product maintenance.

The product uses a diffused silicon piezoresistive sensor, which has the characteristics of high precision, fast response speed and good stability. The product adopts 4-20mA output signal, which can be easily integrated with various industrial control systems.
