5SHX2645L0004 电机驱动器

5SHX2645L0004是一款基于DSP控制的两相步进电机驱动器

具有以下相关参数：

驱动电压：DC24-80V。

适配电流：7A以下。

物理规格：

外壳安装尺寸：180mm125mm47mm。

外形尺寸：120mm x 90mm x 70mm。

工作温度：-20°C~+60°C。

适配法兰：适用于57-86MM的各种型号的两相步进电机。

性能：稳定运行，震动和噪音极小。定位精度最高可达40000步/转。

应用：广泛应用于雕刻机、中型数控机床、电脑绣花机、包装机械等分辨率较高的大、中型数控设备上。

产品特点：最高反应频率可达200KPPS。

设有16档等角度恒力矩细分，最高分辨率40000步/转。

步进脉冲停止超过1.5S时，线圈电流自动减少到设定电流的一半。

光电隔离信号输入/输出。

驱动电流2A/相至7.2A/相16档可调。

单电源输入：DC24-80V。

The 5SHX2645L0004 is a two-phase stepper motor driver based on DSP control

Has the following parameters:

Drive voltage: DC24-80V.

Adaptive current: less than 7A.

Physical specifications:

Shell mounting size: 180mm125mm47mm.

Overall dimensions: 120mm x 90mm x 70mm.

Operating temperature: -20°C~+60°C.

Adaptive flange: Suitable for 57-86MM of various types of two-phase stepper motor.

Performance: Stable operation, minimal vibration and noise. Positioning accuracy up to 40,000 steps/revolution.

Application: Widely used in engraving machine, medium-sized CNC machine tools, computer embroidery machine, 、

packaging machinery and other high resolution large and medium-sized CNC equipment.

Product features: The highest reaction frequency can reach 200KPPS.

With 16 equal Angle constant torque subdivision, the highest resolution 40000 steps/revolution.

When the stepping pulse is stopped for more than 1.5S, the coil current is automatically reduced to half of the set current.

Photoelectric isolation signal input/output.

The drive current is adjustable from 2A/ phase to 7.2A/ phase 16.

Single power input: DC24-80V.
