XVC767AE105 3BHB007209R0105 驱动电源模块

XVC767AE105 3BHB007209R0105是一款

XVC767AE105 3BHB007209R0105 is a drive power module designed for industrial automation and robotics.

Here are some of the main parameters and features of this module:

HMI support: The module supports ControlST V07.00.00C or later Human Machine interface (HMI).

Memory: The module is equipped with 4 GB DDR3-1333 SDRAM memory. This type of memory is typically used to store and process data inside modules,

and the 4GB capacity provides ample space to effectively support complex control algorithms and computational tasks.

Ethernet ports: The module has six Ethernet ports. Five of them are located on the front panel for easy network access.

Non-volatile memory: This module contains non-volatile static random access memory (NVSRAM), which includes 3067 non-volatile program variables, 64

 accumulators, and 338 forces.

Platform configuration features: Support EFA (Embedded Function Automation), embedded EtherCAT (Ethernet for Control Automation Technology), and

embedded PPNG (Predix Process and Notification Gateway) as its platform configuration features.

Storage temperature: The module is designed to withstand a wide storage temperature range of -40 to 85 degrees Celsius.

Energy conversion and output: The drive power module can efficiently convert the input power to the power required by the servo motor or other industrial

equipment, ensuring the stable operation of the equipment.

Protection function: The module usually has overcurrent, overvoltage, undervoltage and overheating protection functions to ensure the safety and reliability of the power supply.

Drive circuit design: The motor control driver uses IR2130 chip to control the on-off and off-off sequence of 6 power tubes to realize the positive and negative control of the motor.

Software design: The main program completes the initialization of DSP, and the A/D conversion interrupt subroutine is used to adjust the speed and current.
