DSMB-01C 控制单元 采用达林顿光电耦合器

DSMB-01C是一种控制单元。

以下是一些关于DSMB-01C的主要参数和特性：

控制方式：支持位置、速度和转矩控制模式。

输入与输出：具有输入输出进行光耦隔离的伺服使能、伺服报警、转矩限制等，使操作流程更规范化。输入接口可由开关、继电器和集电极开路三极管控制，

输出采用达林顿光电耦合器，可与继电器、光电耦合器连接，接口使用更加方便。

位置控制模式：采用光隔离的plus/signal信号、ccw/cwplus信号和A/Bphaseplus信号控制方式，并采用差分驱动的脉冲接收方式，可以有效地抑制干扰。

此外，它还提供了可选的指令脉冲平滑滤波，使系统在加减速过程中平稳地运行。

速度控制模式：支持差分或者单端的模拟-10V~10V信号输入，并提供通过输入端子进行选择的内部1到4速度输入方式，内部速度可调。

转矩控制模式：支持差分或者单端的模拟-10V~10V信号输入。

保护功能：具有过压、过流、过载、超速和编码器异常等多种错误检测机制，以防范潜在的问题。

The DSMB-01C is a control unit.

Here are some of the main parameters and features of DSMB-01C:

Control mode: Position, speed and torque control modes are supported.

Input and output: with input and output for optocoupler isolation of servo enable, servo alarm, torque limit, etc., so that the operation process is more standardized.

The input interface can be controlled by switch, relay and collector open circuit triode, and the output uses Darlington photocoupler, which can be connected with relay

 and photocoupler, and the interface is more convenient to use.

Position control mode: The optical isolation plus/signal, ccw/cwplus signal and A/Bphaseplus signal control mode, and the differential driven pulse receiving mode, can

effectively suppress the interference. In addition, it provides optional instruction pulse smoothing filtering to make the system run smoothly during acceleration and deceleration.

Speed control mode: Support differential or single-end analog -10V~10V signal input, and provide the internal 1 to 4 speed input mode selected by the input terminal,

the internal speed is adjustable.

Torque control mode: Support differential or single-end analog -10V~10V signal input.

Protection: There are multiple error detection mechanisms such as overvoltage, overcurrent, overload, overspeed and encoder anomalies to prevent potential problems.
