DI801 数字输入输出模块

DI801  数字输入输出模块

输入输出特性：该模块具有16个通道，用于24V直流输入，并带有电流吸收功能。每个通道都可以作为一个隔离组，总共有16组，每组都带有电压监控。

指示与连接：模块配备了输入状态指示灯，方便用户观察输入状态。同时，通过可拆卸连接器，用户可以方便地进行过程和电源连接。

电压与阻抗：DI801 模块的输入电压范围在0V到+5V或15V到30V之间。输入阻抗为3.5kΩ。

功耗与电流消耗：模块的典型功耗为2.2W。在+5V模块总线上的电流消耗为70mA，而在+24V模块总线上的电流消耗为0mA。

其他参数：DI801 模块的最大现场电缆长度可以达到600米，额定绝缘电压为50V，介电测试电压为500V。

DI801模块在应用中也有其独特之处。例如，在VFD（变频驱动器）系统中，DI801模块可能用于控制和管理电机的输入信号，有助于实现VFD的节能和低功耗运行。

DI801 digital input/output module

Input/Output characteristics: The module has 16 channels for 24V DC input with current absorption. Each channel can be used as an isolation group, and there are 16 groups in total, each with voltage monitoring.

Indicator and connection: The module is equipped with an input status indicator to facilitate the user to observe the input status. At the same time, process and power connections can be easily made by the user

 through the detachable connector.

Voltage and impedance: The input voltage range of the DI801 module is between 0V to +5V or 15V to 30V. The input impedance is 3.5kΩ.

Power consumption and current consumption: Typical power consumption of the module is 2.2W. The current consumption on the +5V module bus is 70mA, while the current consumption on the +24V module

bus is 0mA.

Other parameters: The DI801 module has a maximum field cable length of 600 meters, a rated insulation voltage of 50V and a dielectric test voltage of 500V.

The DI801 module also has its unique features in the application. For example, in a VFD (variable frequency driver) system, the DI801 module may be used to control and manage the input signals of the motor,

helping to achieve energy-efficient and low-power operation of the VFD.
