CI853K01 电源模块

CI853K01 电源模块

电压与电流：CI853K01  电压一般为24V，而电流范围在100-400A。

通信接口与协议：支持Profibus DP总线标准，通信速率包括9.6kBit/s、19.2kBit/s、45.45kBit/s等多种速率。

CI853K01  具有9针的Sub_D插孔连接器，其管脚定义符合Profibus DP的协议规范。

电源与保护：双电源冗余输入，电源范围为DC(9-36)V，典型工作电压为DC24V，功耗小于4W。

CI853K01  具有DC1500V的电压隔离以及反接保护功能。

具有链路故障和电源故障告警输出功能，触点容量为DC48V/1A。

物理特性与防护：支持拨码开关手动设置通信速率或速率自适应。

配备6个双色LED状态指示灯，以及电源故障继电器输出告警。

CI853K01  具有IP30防护等级，采用波浪纹铝制加强机壳，并使用标准工业35mm导轨安装方式。

防雷与浪涌保护：CI853K01  具有4000V的防雷击能力，以及1.5A的过流保护和600W的浪涌保护功能。

CI853K01 Power module

Voltage and current: The CI853K01 voltage is generally 24V, while the current range is 100-400A.

Communication interface and protocol: Support Profibus DP bus standard, communication rate including 9.6kBit/s, 19.2kBit/s, 45.45kBit/s and other rates.

The CI853K01 has a 9-pin Sub_D jack connector with pin definitions conforming to the Profibus DP protocol specification.

Power Supply and protection: Dual power supply redundancy input, power supply range is DC(9-36)V, typical operating voltage is DC24V, power consumption is less than 4W.

CI853K01 has DC1500V voltage isolation and reverse protection function.

The contact capacity is DC48V/1A, and the link fault and power fault alarms are output.

Physical features and protection: Supports the DIP switch to manually set the communication rate or rate adaptive.

Equipped with 6 two-color LED status indicators, as well as power failure relay output alarms.

The CI853K01 features IP30 protection, a corrugated aluminum reinforced housing and a standard industrial 35mm rail mount.

Lightning protection and surge protection: The CI853K01 has a 4000V lightning protection capability, as well as 1.5A overcurrent protection and 600W surge protection.
