3HAB8101-1809A 模块驱动糸统
3HAB8101-1809A 通信速率:支持多种通信速率,包括9.6kBit/s、19.2 kBit/s、45.45kBit/s、93.75kBit/s、187.5kBit/s、500kBit/s、1.5MBit/s、6MBit/s以及12MBit/s。
电源:支持双电源冗余输入,电压范围为DC(9-36)V,典型值为DC24V,功耗小于4W。具有DC1500V电压隔离和反接保护功能,采用工业端子接口。
接口:具有9针的Sub_D插孔连接器,管脚定义符合Profibus DP的协议规范。支持Profibus DP总线标准。
3HAB8101-1809A 保护:具有防雷击(4000V)、过流(1.5A)和浪涌保护(600W)功能,同时提供链路故障和电源故障告警输出。
3HAB8101-1809A 其他特性:支持标准规范中的预定通信速率,并支持拨码开关手动设置其全部标准速率或速率自适应。具有6个双色LED状态指示灯和电源故障继电器输出告警。
电接口具有4000V的防雷和1.5A的过流保护,以及600W的浪涌保护。此外,它还具有IP30防护等级和波浪纹铝制加强机壳,采用标准工业35mm导轨安装方式。
3HAB8101-1809A module driver system
3HAB8101-1809A Communication rate: Various communication rates are supported, including 9.6kBit/s, 19.2 kBit/s, 45.45kBit/s, 93.75kBit/s, 187.5kBit/s, 500kBit/s, 1.5MBit/s, 6MBit/s, and 12MBit/s.
Power supply: Supports dual power supply redundancy input, voltage range is DC(9-36)V, typical value is DC24V, power consumption is less than 4W. With DC1500V voltage isolation and reverse
protection function, using industrial terminal interface.
Interface: A 9-pin Sub_D jack connector with pin definition conforming to the Profibus DP protocol specification. Supports Profibus DP bus standard.
3HAB8101-1809A Protection: Provides lightning protection (4000V), overcurrent protection (1.5A), and surge protection (600W), and outputs link fault and power fault alarms.
3HAB8101-1809A Other features: Support the predetermined communication rate in the standard specification, and support the dip switch to manually set its full standard rate or rate adaptive.
Features 6 two-color LED status indicators and power failure relays to output alarms. The electrical interface has 4000V lightning protection and 1.5A overcurrent protection, and 600W surge
protection. In addition, it has IP30 protection rating and wavy aluminum reinforced housing with standard industrial 35mm rail mounting.
