3BHB017688R0001 通道断电器模块

3BHB017688R0001 通道断电器模块

机械特性：

外形尺寸：132mm105mm52mm。

外壳：IP30防护等级，具有波浪纹铝制加强机壳。

安装方式：35mm DIN导轨安装。

净重：800g。

工作环境：

工作温度：-10~70℃（还有-40~+85℃宽温可选）。

相对湿度：≤90%（无冷凝）。

存放温度：-40~80℃。

测试认证：该模块已通过多项测试认证，包括IEC61000-4-2(ESD)、IEC61000-4-3(RS)、IEC61000-4-4(EFT)、IEC61000-4-5(Surge)、IEC61000-4-6(CS)、

IEC61000-4-8(MS)以及IEC61000-4-11(Dips)等，确保了其在各种电磁环境下的稳定性和可靠性。

控制技术与通信功能：该模块集成了先进的控制技术和通信功能，为工业自动化系统提供了强大的支持和保障。

具有逻辑独立双总线电接口，可以实现电接口的备份或者单设备接入双冗余总线系统，增强了系统的可靠性和稳定性。

具备出色的光纤通信能力，采用双光口链形网络的光纤总线，可以实现多网段的Profibus DP总线连接，最多支持200个网段。

支持多模和单模光纤，传输距离分别可达2Km和20Km。

3BHB017688R0001 Channel breaker module

Mechanical characteristics:

Overall dimension: 132mm105mm52mm.

Housing: IP30 protection grade, with wavy aluminum reinforced housing.

Mounting method: 35mm DIN rail mounting.

Net weight: 800g.

Working environment:

Operating temperature: -10~70℃ (and -40~+85℃ wide temperature optional).

Relative humidity: ≤90% (no condensation).

Storage temperature: -40~80℃.

Test certification: This module has passed a number of test certification, They include IEC61000-4-2(ESD), IEC61000-4-3(RS), IEC61000-4-4(EFT),

IEC61000-4-5(Surge), IEC61000-4-6(CS), IEC61000-4-8(MS), and IEC61000-4 -11(Dips), etc., to ensure its stability and reliability in various electromagnetic environments.

Control technology and communication function: The module integrates advanced control technology and communication function to provide strong support and guarantee

 for industrial automation system.

With a logic independent dual bus electrical interface, it can realize the backup of electrical interface or single device access to dual redundant bus system, which enhances the

 reliability and stability of the system.

With excellent optical fiber communication capabilities, the use of dual-optical port chain network fiber bus, can achieve multi-network segment Profibus DP bus connection,

support up to 200 network segments.

Support multi-mode and single-mode fiber, transmission distance up to 2Km and 20Km respectively.
