3BHB005243R0105 位移控制外表

3BHB005243R0105 位移控制外表

3BHB005243R0105  产品特点：

多功能、高可靠性的ssi位移控制外表。

采用DSP算法和CPLD配置进行适当的调整来实现不同的硬件功能模块。

励磁交流接触控制器模块，用于旋转电机中产生磁场的方式。

通常具有友好的人机界面和远程监控功能，方便用户进行参数设置、故障诊断和远程维护。

3BHB005243R0105  应用领域：

该产品广泛应用于水利工程、排水系统、水处理厂、能源生产、海洋和沿海工程等领域，用于精确控制水位、流量、涡轮旋转等。

量程与精确度：

量程为100~380。

精确度为0.1~1.8。

规格尺寸：

尺寸为20018050mm。

3BHB005243R0105  通信与接口：

支持一路RS485全数字量输出，自带通讯协议，也可依照客户要求。

通常支持多种通信协议和接口标准，可以与其他设备或系统进行无缝连接和集成。

控制参数：

输入信号为值同步串行ssi信号（单圈、多圈编码器、直线传感器10~26位）。

作业电压为220VAC。

输出方式包括一路4~20ma模拟量输出和一路RS485全数字量输出。

3BHB005243R0105  环境适应性：

环境温度范围为-10~60℃。

相对湿度小于90%。

3BHB005243R0105 Displacement control exterior

3BHB005243R0105 Product Features:

Multi-functional, highly reliable ssi displacement control exterior.

DSP algorithm and CPLD configuration are used to make appropriate adjustments to realize different hardware function modules.

The excitation AC contact controller module is used to generate a magnetic field in a rotating motor.

Usually has a friendly man-machine interface and remote monitoring function, convenient for users to set parameters, fault diagnosis and remote maintenance.

3BHB005243R0105 Application Field:

The product is widely used in hydraulic engineering, drainage systems, water treatment plants, energy production, Marine and coastal engineering and other fields

for precise control of water level, flow, turbine rotation and so on.

Range and accuracy:

The range is 100~380.

The accuracy is 0.1 to 1.8.

Specification size:

The size is 20018050mm.

3BHB005243R0105 Communication and Interface:

Support one RS485 full digital output, with its own communication protocol, also according to customer requirements.

It usually supports multiple communication protocols and interface standards, and can be seamlessly connected and integrated with other devices or systems.

Control parameters:

The input signal is the value synchronous serial ssi signal (single turn, multi-turn encoder, linear sensor 10-26 bits).

Operating voltage is 220VAC.

The output mode includes one 4 to 20ma analog output and one RS485 full digital output.

3BHB005243R0105 Environmental Adaptability:

The ambient temperature ranges from -10 to 60 ° C.

The relative humidity is less than 90%.
