3BDH000320R0101 电位计模块

3BDH000320R0101 电位计模块

产品用途：3BDH000320R0101该模块是一款电位计模块，用于连接不同类型的3线传感器，如100Ω Pt和120Ω Ni RTD，以及高达5kΩ的电位计。

通道与保护：模块拥有6个输入通道，每个通道都具备高达240Vrms的连续过载保护，以防止意外接线错误。此外，过载通道不会对模块中的其他通道产生不利影响。

瞬态保护与隔离：模块的瞬态保护符合ANSI/IEEE C37.90.1标准，而输入至总线的隔离为强大的1500Vrms。

3BDH000320R0101采样率与通道配置：默认情况下，所有通道都是启用的，但可以禁用未使用的通道，以提高启用扫描的通道的采样率。

监控与警告功能：模块提供高、低、高-高和低-低警报，以确保最佳的工艺流程和故障安全应用。

3BDH000320R0101尺寸与安装：模块的尺寸约为47 x 131 x 111毫米，重量约0.4 kg，可以安装在35 mm的DIN导轨上（DIN EN 50 022）。

电源电压：模块的电源电压为24 V DC（+-20%）。

3BDH000320R0101 potentiometer module

Product Usage: 3BDH000320R0101 This module is a potentiometer module for connecting different types of 3-wire sensors such as 100Ω Pt and 120Ω Ni RTD, as well as potentiometers up to 5kΩ.

Channels and protection: The module has 6 input channels, each with continuous overload protection of up to 240Vrms to prevent accidental wiring errors. In addition, overload channels do not

adversely affect other channels in the module.

Transient protection and isolation: The transient protection of the module complies with ANSI/IEEE C37.90.1 standards, while the isolation of the input to the bus is a powerful 1500Vrms.

3BDH000320R0101 Sampling Rate and Channel Configuration: By default, all channels are enabled, but unused channels can be disabled to improve the sampling rate of scannable channels.

Monitoring and Warning functions: Modules provide high, low, high-high and low-low alarms to ensure optimal process flow and fail-safe applications.

3BDH000320R0101 Dimensions and mounting: The module measures approximately 47 x 131 x 111 mm, weighs approximately 0.4 kg and can be mounted on a 35 mm DIN rail (DIN EN 50 022).

Power supply voltage: The power supply voltage of the module is 24 V DC (+-20%).
